Type: ESX10-S

Description

The model ESX10-Sxxx extends our product group of electronic overcurrent protection devices for DC 24 V applications. At a width of only 12.5mm it provides selective protection for all DC 24 V load circuits. This is achieved by a combination of active electronic current limitation in the event of a short circuit and overload disconnection typically from 1.2 times rated current. The ESX10-S is a plug-in type and thus allows quick and easy installation for groups of devices with several circuits on the power distribution systems Module 17plus and SVSxx.

Voltage rating
Voltage rating
Rated voltage 1 A
2 A
3 A
4 A
5 A
6 A
7 A
8 A
9 A
10 A
Number of poles 1-pole
Load disconnection short circuit: typically 100 ms
overload: typically 3 s
without physical isolation at short circuit/overload
trip times:
short circuit: typically 100 ms
overload: typically 3 s
Current limitation typically 1.4 x IN
Signal output Meldeausgang F, Statusausgang SF
Status indication 1 LED green/orange/red: status/fault
Temperature range
Terminal design blade terminals 6.3 mm
Certificates UL 2367 DC 24 V 1...10 A UL 508 DC 24 V 1...10 A

Applications

  • Automation
  • Automobile production
  • Chemical, Oil & Gas
  • Mechanical engineering
  • Pharmaceutical & Food
  • Power Engineering DC 24 V
